Flange Union Pipe Size - Pipe Fitting
Item: Flange Union
Max. Pressure: 175 psi@-20 Degrees to 150 Degrees F
Standards: UL: FM Approved: ASME B16.4
Temp. Range: -20 Degrees to 150 Degrees F
Product Introduction
● Item: Flange Union
● Max. Pressure: 175 psi@-20 Degrees to 150 Degrees F
● Standards: UL: FM Approved: ASME B16.4
● Temp. Range: -20 Degrees to 150 Degrees F
● Basic Fitting Material: Metal
● Specific Fitting Shape: Union
● Basic Fitting Shape: Union
● Seat Material Brass
Product Parameter (Specification)
No. | Part | Material |
1 | Bolts | Zinc Coated Steel |
2 | Nuts | Zinc Coated Steel |
3 | Flange | Cast Iron W/Galvanized |
4 | Gasket | EPDM |
5 | Flange | Cast Iron W/Galvanized |
6 | Insulator | Plastic |
7 | Solder connection | Lead Free Brass |
Item No. | Size | A | B |
CLFU015-1 | 2-1/2" | 1.62 | 1.02 |
CLFU015-2 | 3" | 1.89 | 1.26 |
Products Details
Production Procedure
Factory Review
Our factory covers about 15000sqm, which the floor space is about 10000sqm. We have have hundreds of employees, including 16 managers and engineers. Our fixed assets valued about RMB15000000.
The factory is specialized in producing a variety of high intensity particular fasteners. It mainly produces Dielectric Pipe Unions, pipe clamps and non-standard, irregular high intensity particular bolts and nuts.
Deliver, Shipping and Serving
● Packing Details: 1pc/polybag+10pcs/inner+Carton or follow customer requirements.
● Delivery Details: usually about 25 days after receiving the deposite. Fast delivery requirements is acceptable.
● Shippment: usually by sea, if customer is in urgent need of the good, we can also deliver by air or by express like DHL, UPS Fedex etc.
FAQ
Q1: Shipping terms?
A: By air express/by express/by sea options.
Q2: Are you a manufacturer?
A: Yes.
Q3: What certificate do you have?
A: ISO9001, Lead Free and UPC
Q4: Can support OEM order?
A: Yes.
Q5: Samples are available before order?
A: Yes
